Desktop Laser Marking Machine

Sino-Galvo Tech, is the largest laser galvo scanner manufacturer in China, which occupy over 60% market of marking scanner with our quality and service. Our own developed scanner and laser marking control system will bring you extremely fast and precise laser marking.

Send Inquiry

Why Choose Us

Products Description

Select the laser suitable for the power or the power density of the material processed, could process on the most of metal and non-metal material.
Laser is processed in the non-mechanical “tool”, no mechanical extrusion and stress for the material, no tool wear, no toxic, no pollution.
Small material consumption, no thermal deformation.
Easy to operate.
Precise positioning with three- dimensional workbench.
High anti-falsification.
Unique auto location function.
Low cost, high benefit.

PRODUCT SPECIFICATIONS

Laser
Power	20W
Wavelength	1064nm
Beam Quality	M2<1.6
Pulse Repetition Frequency	50-120KHz
Standard Marking Area	110×110mm
Optional Marking Area	110×110mm
Marking Depth	≤2.0mm
Linear Speed	≤14000mm/s
Min Line Width	0.01mm
Min Character Size	0.05mm
Repeat Accuracy	±0.001mm
Consumed Power	≤1000W
Maintenance Time	100,000hrs
Power Supply	Single Phase 110V/220V/50-60Hz
Cooling:	Air cooling

Laser Power
Rated Input Voltage	220V/110V(Optical)±5%
Input Power	0.5KW
Maximum Output Current	24.0A
Adjustment Range for the Output Current	0A~20.0A
Current Ripple	≤0.4%
Working Temperature	0~35℃

Galvanometer System
Analog Input Impedance	100KΩ±1
Position Output Impedance	1 KΩ±1
Position Output Ratio	0.5V/ Mechanical deflection Angle
Input Voltage	±15VDC/±22VDC
Electronic Circuit Stability	20PPM/℃
Working Temperature	0~50℃

Worktable
Table Loading Capacity	5 KG
Platform Size	196×216mm
Outline Size	493400487mm
Stroke of XY	100mm
