Product Description
Model: JD1605
Product Name: Galvanometer motor for 3d printer
Material of outer holder: Aluminum Alloy
Color Of Outer holder: Silver
Product Size: 22x47.7mm 29.5x52.2mm
Gross Weight (Including wire and power supply): 52.0kg
Package Size: 29x23x14cm
Function & Application: Laser marking, 3D printing, Laser cutting.
Parameter Details
Motor Specification of JD1605:
Working Temperature | 0-45°C |
Linearity | 99.9% |
Setting Time | ≤0.3ms |
Scale Drift | <40PPM/°C |
Zero Drift | <15μRad./°C |
Long-term Drift Over 8 Hours | <0.5mRad |
RMS Current | 2A |
Peak Current | 10A(Max) |
Maximum Scan Angle | ±15° |
Storage Temperature | -10 to +60°C |
Resolution | 12μrad |
Repeatability | 8μrad |
Input Aperture | 10mm |
Beam Displacement | 10.7mm |
Motor Weight | 52g |
Frequency | ≤1000Hz |
Servo Driver Board Specification of JD1605:
Input Voltage | ±15VDC |
Interface Signals Digital | XY2-100 |
Analog Signal Input Resistance | 200K±1% Ω |
Position Signal Input Resistance | 1K±1% Ω |
Position Signal Input Scale Factor | 0.33V/° |
Position Signal Output Scale Factor | 0.33V/° |
Working Temperature | 0-45°C |
Dimension(L×W×H) | 75×50×28mm |
Application:
This model JD1605 galvanometer is widely used in 3d prnting field,
3d printing is a new technology in manufacturing. And there are many technologies in 3D printing field, for jewelry and industrial board, desktop SLA 3D printer is the best choice.
For industrial and jewelry designer, you got an idea, and get a model within one day through 3D printing. Beside, it has the belowing advantages:
1)High precision
2)High speed
3)Without of the limited in complicated structure.
And in the printer, galvo sanner is the core component Sino-Galvo JD1605 galvo scanner motor has introduced the most advanced international photoelectric sensor control mode, and carried on the comprehensive optimization design from the scanner mechanical aspects, greatly reduced the scanner size, improved the marking speed and precision, the products performance and stability has reached the leading level at home and abroad.
JD1605 Motor Size Drawing and Descriptions
