Product Description
Model No.:SG8220
Small Step Response time:0.6ms
Input Aperture:20mm
Speed:6000mm/s
Input Voltage:±24VDC
SG8220 Motors & Drive board technical parameters
Motor Specification
Working Temperature | 0℃-45℃ |
Linearity | 99.9% |
Setting Time | ≤0.8ms |
Scale Drift | <40PPM/℃ |
Zero Drift | <15μRad./℃ |
Long-term Drift Over 8 Hours | <0.5mRad |
RMS Current | 3.5A |
Peak Current | 20A(Max) |
Maximum Scan Angle | ±15° |
Storage Temperature | -10℃ to +60℃ |
Resolution | 12μrad |
Repeatability | 8μrad |
Input Aperture | 20mm |
Beam Displacement | 26mm |
Motor Weight | 280g |
Frequency | ≤500Hz |
Servo Driver Board Specification
Input Voltage | ±24VDC | |
Interface Signals | Digital | XY2-100 |
Analog | ±5V, ±10V | |
Analog Signal Input Resistance | 200KΩ±1% (Differential input) | |
Position Signal Input Resistance | 1KΩ±1% | |
Position Signal Input Scale Factor | 0.33V/° | |
Position Signal Output Scale Factor | 0.33V/° | |
Working Temperature | 0℃-45℃ | |
Dimension(L×W×H) | 80×54×33mm | |
