Product Description
Model: SG8330
Product Name: large format 3d galvo scanner
Material of outer holder: Aluminum Alloy
Color Of Outer holder: Sliver& Red
Product Size: 183xx101mm
Gross Weight (Including wire and power supply): 2.5kg
Package Size: 29x13x14cm
Function & Application: Common marking, rotary marking, flying marking and other applications.
Product Advantages
1.Designed with analog and digital interface;
2.Adopted the unique double circulation water cooling system;
3.The input aperture is 30mm.
4.Mainly used in high-power laser welding and cutting.
5.It has the characteristics of zero drift, higher speed, lower temperature and easy installation, etc.
Parameter Details
Motor Specification
Working Temperature | 0-45°C |
Linearity | 99.9% |
Setting Time | ≤1.2ms |
Scale Drift | 40PPM/°C |
Zero Drift | <15μRad./°C |
Long-term Drift Over 8 Hours | <0.5mRad |
RMS Current | 4.0A |
Peak Current | 25A |
Scan Angle | ±12.5° |
Storage Temperature | -10 to +60°C |
Resolution | 12μrad |
Repeatability | 8μrad |
Input Aperture | 30mm |
Beam Displacement | 35.5mm |
Motor Weight | 750g |
Frequency | ≤400Hz |
Servo Driver Board Specification
Input Voltage MAX.RMS | ±24VDC | |
Interface Signals | Digital | XY2-100 |
Analog | ±5V, ±10 | |
Analog Signal Input Resistance | 200K±1% Ω | |
Position Signal Input Resistance | 1K±1% Ω | |
Position Signal Input Scale Factor | 0.33V/° | |
Position Signal Output Scale Factor | 0.33V/° | |
Working Temperature | 0-45°C | |
Dimension(L×W×H) | 80×54×33mm | |
FAQ:
Q: How can you guarantee your sales' quality?
A: Sino-Galvo guarantees that every set of galvo scanner are under rigorous testing before they are delivered to you, to ensure the excellent performance of all products.
Q: How can you connect with us after purchased our products?
A: After purchased our products, if you have any questions, please contact our service hot-line: 86-10-62979055/62979755.
Q: Where is your factory located? How can I visit there?
A: We are located in Haidian District, Beijing, China. All our clients from home and abroad are warmly. Welcome to visit us.
Q: How about the payment?
A:We support T/T, PayPal, Cash, Escrow and Western Union.
Q: How about the after sales service?
A: 1. If you are not satisfied with our products, we will provide free exchange service within 3 months.
2. Sino-Galvo will provide free repair service for what you purchased within 18 months.
3. Scanning mirrors and housing of galvo scanners are not in the range of warranty and replacement.
4. We commit the maintenance service less than 48 hours after received the products.
5. Unauthorized to tearing the seal, replace the parts or damage the products, we shall not assume the warranty responsibility.
