Product Description
Model:JD2208
Product Name: Galvo Head Laser
Material of outer holder: Aluminum Alloy
Color Of Outer holder: Sliver
Product Size: 98x126x105mm
Gross Weight (Including wire and power supply): 3kg
Package Size: 29x13x14cm
Function & Application: Common marking, rotary marking, flying marking and other applications.
Product Advantages
Sino-Galvo's galvanometer motors are designed by adopting the magnet-moving structure, combining the most advanced international photoelectric sensor technology and the PDM control mode, and using the Military-grade processes and technologies.
The model JD2208 galvo scanner has the good running stability, high positioning accuracy, fast marking speed, strong anti-interference ability, the overall performance of JD2208 has reached the international leading level in this field.
Parameter Details
Motor Specification of galvanometer drivers
Working Temperature | 0-45°C |
Linearity | 99.9% |
Setting Time | ≤0.6ms |
Scale Drift | 40PPM/°C |
Zero Drift | <15μRad./°C |
Long-term Drift Over 8 Hours | <0.5mRad |
RMS Current | 2.0A |
Peak Current | 15A(Max) |
Scan Angle | ±11° |
Storage Temperature | -10 to +60°C |
Resolution | 12μrad |
Repeatability | 8μrad |
Input Aperture | 14.0mm |
Beam Displacement | 18.7mm |
Motor Weight | 130g |
Frequency | ≤600Hz |
Servo Driver Board Specification:
Input Voltage MAX.RMS | ±15VDC |
Interface Signals Digital | XY2-100 |
Position Signal Input Resistance | 1K±1% Ω |
Position Signal Input Scale Factor | 0.33V/° |
Position Signal Output Scale Factor | 0.33V/° |
Working Temperature | 0-45°C |
Dimension(L×W×H) | 75×50×28mm |
FAQ:
Q: What is The principle of the galvanometer scanner ?
A: Galvanometer Scanner Working Principle is: input a position signal, galvo motor will swing a certain angle according to the conversion ratio of certain voltage and angle. The whole process adopts closed-loop feedback control, which is composed of five control circuits-- position sensor, error amplifier, power amplifier, position distinguisher and current integrator. Digital galvanometer scanner is to convert the analog signal into a digital signal base on analog galvo scanner principle. Galvanometer scanner is the core component of the marking machine. Laser marking machine performance depends mainly on galvo scanner.
Production Process:
Rough Adjustment Galvo Scanner Testing Assembling
Aging Test(Industrial) Aging Test( Beauty) Dust-free Workshop
