100w Backpack Laser Rust Removing Laser Cleaning Machine
This backpack laser cleaning machine, the light pulse energy is high, the output is stable, the index parameter applicability is strong; The new electronic control system can avoid the problem of excessive ablation at both ends of the cleaning, and achieve efficient and accurate cleaning without damaging the substrate; Small size, light weight, compact structure design, can meet the high altitude, narrow space, outdoor and other scenes of portable or carrying cleaning operations; Parameter adjustment is simple and flexible, and it is set by wireless control panel, which is easy to operate.
Video Show Link： https://www.youtube.com/watch?v=6pOjJx1_0GU
Product advantage
- Wireless control: parameter adjustment is simple and flexible, set by wireless control panel, easy to operate;
- No damage to the substrate: The new electronic control system can avoid the problem of excessive ablation at both ends of the cleaning, and achieve efficient and accurate cleaning without damaging the substrate;
- Light and portable: The equipment is small in size, light in weight, and compact in structure design, which can meet the portable or piggyback cleaning operations in high-altitude, narrow space, outdoor and other scenarios.
Application scenarios
technical specification
| Product model | JHC-LC-100NDA |
| Cleaning efficiency（m2/h） | Rust: 4-5m2/h, light oil: 6-7m2/h, aluminum oxide: 4-5m2/h, paint: 2-3m2/h (the paint thickness will affect the cleaning effect) |
| Laser type | 1064nm, pulse optical fiber laser |
| Average power | 100W |
| Single pulse energy | 1.5mj |
| Output configuration | Dual galvanometer portable output head, under the condition of field mirror focal length of 254mm, the output shape shall be spiral (length<120mm, width<50mm), square (length<120mm, width<120mm), round (diameter<120mm), and cross mode (length<120mm) |
| Cooling | Air cooling |
| Weight | Body weight: 9.8±0.1kg (excluding battery) / 10.7±0.1kg (including battery，Battery life≥30 minutes); output head weight: ＜0.95Kg |
| Overall dimension | 10.9*5.2*15.5 inch |
| Output head button | Light can be emitted only when the laser safety button is pressed, and 10mm self-reset switch is used. |
| Transmission optical fiber | 1.5m transmission optical fiber wrapped at the industrial level |
| Operation control | Wireless control tablet |
| Power supply | 100-240V AC or lithium battery |
| Use environmental temperature | 10-40℃ |
