Product Description
Model:JS1550
Product Name: Co2 Scar removal galvo scanner head
Material of outer holder: Aluminum Alloy/ Resin
Color Of Outer holder: Silver/black/yellow
Product Size: 177.1x295.9mm
Gross Weight (Include laser control system): 3.8kg
Package Size: 32x41x15cm
Function & Application: Skin rejuvenation
Product Advantages
High-end laser fractional Galvo-scanners which specially applied to 1550nm laser devices.
Parameter Details
Motor Specifications
Working Temperature | 0-45°C |
Linearity | 99.9% |
Setting Time | ≤0.35ms |
Scale Drift | 40PPM/°C |
Zero Drift | <15μRad./°C |
Long-term Drift Over 8 Hours | <0.5mRad |
RMS Current | 2.0A |
Peak Current | 10A(Max) |
Maximum Scan Angle | ±15° |
Storage Temperature | -10 to +60°C |
Resolution | 12μrad |
Repeatability | 8μrad |
Input Aperture | 5.0-7.0mm |
Beam Displacement | 10.7mm |
Motor Weight | 13g |
Frequency | ≤1000Hz |
Serve Driver Board Specification
Input Voltage MAX.RMS | ±15VDC |
Interface Signals Analog | ±5V |
Fault signal output(TTL level) | H is for galvanometer working normally, L for galvanometer failure |
Analog Signal Input Resistance | 200KΩ±1% |
Position Signal Input Resistance | 1KΩ±1% |
Position Signal Input Scale Factor | 0.33V/° |
Position Signal Output Scale Factor | 0.33V/° |
Working Temperature | 0-45℃ |
Dimension(L×W×H) | 75×50×28mm |
FAQ:
1. Q: Are you a trading company or a factory?
A: We are a professional factory for 19 years and our products are very popular both in domestic and abroad.
2. Q: How about the aftermarket service?
A: 1. If you are not satisfied with our products, we will provide free exchange service within 3 months.
2. Sino-Galvo will provide free repair service for what you purchased within 18 months.
3. Scanning mirrors and housing of galvo scanners are not in the range of warranty and replacement.
4. We commit the maintenance service less than 48 hours after received the products.
5. Unauthorized to tearing the seal, replace the parts or damage the products, we shall not assume the warranty responsibility.
3. Q: What kind of payment terms support?
A: T/T, Western Union, International Credit Card, L/C and others.
